4-40ton Excavator Grapple Bucket SY65 SY155 SY235 SY365 Excavator Tilt Bucket

Brand Name : 1

Model Number : DPSTTB900

Certification : ISO CE

Place of Origin : CHINA

MOQ : 1

Price : 100-700

Supply Ability : 5000 Pcs Per Month

Delivery Time : 5-7Working Days

Packaging Details : Export Wooden Cases /Pallet

Color : Customer Required,Customer's Request,any color

Warranty : 6 Months-12months

Type : Excavator Spare Parts

Application : Excavator,stones,woods etc

Material : Q345B,NM360/400,Q345B/NM360/HARDOX500

After-sales service provided : Video technical support,Online support

Condition : New

Usage : load or unload sand or something else

Name : excavator Grapple bucket,bucket

Packing : Wooden Pallet or Customized

Suitable excavator : All Brands' All Model

Part name : Grapple,Excavator Bucket

Origin : YANTAI,China

Contact Now

What is a Tilt Ditch Cleaning Bucket?
A tilt ditch cleaning bucket does exactly what its name suggests. This specialized cleaning bucket shares a similar design to a grading bucket. It can tilt at a 45-degree angle to allow the operator to work at difficult angles. Many consider this a “finishing” bucket used at the end of a project for tidying and creating smooth finishes.

Selecting an Excavator Bucket Size
Most construction projects benefit from a bucket that will increase productivity by reducing the number of passes the tool needs to make. Select the biggest excavator bucket that won’t compromise efficiency — except when you have a particular size requirement, like when digging a trench.

Suitable:
Designed to work for standard ditching, grading and light
material loading without excavator moving.

Features:
1.Controlled to swing by cylinder and the biggest angle
is up to 45°;
2.Reduce the wearing of machine and fuel consumption.

What is a General-Purpose Bucket?
A general-purpose bucket has the most versatility and is appropriate for many excavating tasks. It is also known as a digging bucket, and it is the standard attachment that comes with an excavator. If you rent an excavator without specifying a bucket, you’ll probably receive a general-purpose bucket. It comes with short, blunt teeth that work great on soil and are available in many sizes for various applications.
Here are some of the materials you can move with an all-purpose excavator bucket:
Dirt
Sand
Topsoil
Clay
Gravel
Loam
Silt
Ground with loose gravel or stones
Frost-covered soil

Model	Suitable Weight Pin Diameter		Pin Distance	Length	Width	Height	Arm Width
Unit	ton	mm	mm	mm	mm	mm	mm
DPSTTB-02	4-6	45	245	1200	790	920	170
DPSTTB-04	6-8	50	310	1400	870	1010	220
DPSTTB-06	12-18	60-65	360	1700	1070	1210	260
DPSTTB-08	19-24	80	465	1900	1200	1480	340
DPSTTB-10	25-36	90-100	530	2030	1360	1730	390

TYPE	MATERIAL
Bucket(GP)	Q345B	Mainly used for excavation and sand, gravel and soil and other light load operating environment.
Bucket(HD)	Q345+NM400	Mainly used for digging hard soil, mixed with a relative soft stone and clay, softer stones and other light load operating environment.
Bucket(HDX)	Q345+NM400/HARDOX400	Used for mining hard gravel mixed with hard soil, sub-hard stone or flint, after blasting or loading, and heavy-loading.
