Top Type Mounted Hammer Rock Breaker SB10 SB20 Chisel Tool 40mm For 0.8-2ton Excavator

Name: Top Type Mounted Hammer Rock Breaker SB10 SB20 Chisel Tool 40mm For 082ton Excavator
Brand: Dopro
Price: 70 USD

China Top Type Mounted Hammer Rock Breaker SB10 SB20 Chisel Tool 40mm For 0.8-2ton Excavator wholesale

Brand Name : Dopro

Model Number : DPTB400

Certification : ISO CE

Place of Origin : CHINA

MOQ : 1

Price : 70-700

Supply Ability : 7000 Pcs Per Month

Delivery Time : 5-7 Working Day

Packaging Details : Export Wooden Cases /Box

Warranty : 12 Months

Color : Customer Required,any color

Application : Mining,Crawler Excavator,Construction

Type : Top type/ Side type/ Box type

After-sales service provided : Online support,Video technical support

Material : 42CrMo,20CrMo

Chisel diameter : 40 - 210 mm

Condition : 100%new

Name : hydraulic breaker for backhoe loader,Hydraulic hammer rock breaker for excavator,silenced type road construction hydraulic breaker for mini excavator,Hydraulic breaking hammer

Part name : Hydraulic hammer rock breaker,Rock Breaker /Mini Hydraulic Hammer for Excavator and Wheel Loader

Product name : Soosan Hydraulic Breaker,Hydraulic Hammer Rock Breaker,Hammer For Excavator

Oem : yes,Avaliable

System : Hydraulic-gas System

Oem/odm : Available,Acceptable

Contact Now

Top type Mounted Hammer Rock Breaker SB20 chisel tool 40mm Suitable for 0.8-2ton Excavator

What is top type breaker

Top Type Breaker: This hydraulic rock breaker is designed to be mounted on the top of an excavator or other heavy machinery

What is the difference between side type and top type hydraulic breakers?

Type of material: Different hydraulic rock breakers are better suited for breaking apart different materials. For example, a side-type breaker is better for breaking concrete walls, while a top-type breaker is better for breaking apart large rocks.

For example, a side-type breaker is better for breaking concrete walls, while a top-type breaker is better for breaking apart large rocks. 3. Machine compatibility: Ensure that the hydraulic rock breaker is compatible with the carrier machine, such as an excavator or backhoe loader used for the job

What are the different types of hydraulic breakers?
Classification according to the working principle: Hydraulic breakers are divided into three categories: full hydraulic type, liquid-gas combined type and nitrogen explosion type.

DOPRO FEATURE & BENEFITS

1.Noisier than the Slient type but less overall weight makes and it for easier positioning.

2.Easy-control and easy-position make it more convenient to excavation work Without side wight,reducing the rate of chisel breakage.

3.Parts exchanging quickly and Longer operation range for distance working More powerful cause of body verticality.

SPECIFICATION
Model			DPTB400	DPTB450	DPTB530	DPTB680	DPTB750	DPIB1000
Suitable Excavator	Min	ton	0.8	1.2	25	4	6	11
	Max	ton	2.5	3	45	7	9	16
	Suitable	ton	1	2	3	6	7	14
Tool (Moil Type)	Weight	Kg	4	6	9	20	25	59
Tool (Moil Type)	Diameter	mm	40	45	53	68	75	100
Operating Weight (Tool+MO)		Kg	90	110	135	273	304	516
Operating Weight (Tool+MO)		Ib	165	190	353	714	838	1874
Height		mm	1150	1254	1313	1602	1869	2358
Operating Pressure (Breaker)		bar	80～100	80~100	90~120	95~130	100~140	150～170
Operating Pressure (Breaker)		psi	1,160～1450	1,160~1,450	1,305~1,740	1,377~1,885	1,450~2,030	2,175~2465
Setting Pressure (Machine)		bar	150	150	150	170	180	200
Setting Pressure (Machine)		psi	2175	2175	2175	2465	2610	2900
Impact Rate		bpm	800～1,400	700～1,200	600~1,100	500～900	400~800	350~700
BackHead Pressure (N2-Gas)		bar/psi	14/203	14/203	16/232	16/232	16/232	16/232
Required Oil How		l/min	15～30	20~40	25~50	40~70	50～90	80~110
Required Oil How

SPECIFICATION
Model			DPTB1350	DPTB1400	DPTB1500	DPTB1550	DPTB1650	DPTB1750
Suitable Excavator	Min	ton	18	10	25	28	30	40
	Max	ton	21	26	20 0	35	40	55
	Suitable	ton	20	24	24	34	40	50 0
Tool (Moil Type)	Weight	Kg	125	129	129	193	233	311
Tool (Moil Type)	Diameter	mm	135	140	150	155	165	175
Operating Weight (Tool+M/O)		Kg	1450	1780	2100	2700	2995	4100
Operating Weight (Tool+M/O)		Ib	3968	4453	4453	5820	7055	11089
Height		mm	2691	2828	3055	3215	3395	3736
Operating Pressure (Breaker)		bar	160～180	160~180	160～180	160~180	160~190	160～200
Operating Pressure (Breaker)		psi	2,320～2,610	2,320~2,610	2,320~2,610	2,320~2,610	2,276~2,702	2,276~2,845
Setting Pressure (Machine)		bar	210	210	210	220	240	240
Setting Pressure (Machine)		psi	3045	3045	3045	3190	3480	3480
Impact Rate		bpm	350～600	350～500	300~450	300~450	250～400	150～350
Back Head Pressure (N2-Gas)		bar/psi	16/232	16/232	16/232	16/232	17/246	18/261
Required Oil Fow		l/min	100～150	120～180	150~210	180～240	200~260	210~290
Required Oil Fow

Top Type Mounted Hammer Rock Breaker SB10 SB20 Chisel Tool 40mm For 0.8-2ton Excavator

Product Tags:

Top Type Hammer Rock Breaker

Mounted Hammer Rock Breaker

Top Type Mounted Hammer Rock Breaker SB10 SB20 Chisel Tool 40mm For 0.8-2ton Excavator Images
